Compact Size 12V LiFePO4 Battery Pack 40Ah Lithium Battery In Light Weight

Customer Reviews
Good! HECO lithium batteries are of good quality and reasonable in price. I’d like to cooperate with such partner.

—— Jan Jacobsen

We are happy to get acquaintances with HECO. They are very professional!

—— Zhamal Ramazanov

HECO has a good supply chain of cells as well as other components. They always can supply me what i want.

—— Marco Dini

I'm Online Chat Now

Compact Size 12V LiFePO4 Battery Pack 40Ah Lithium Battery In Light Weight

Compact Size 12V LiFePO4 Battery Pack  40Ah Lithium Battery In Light Weight
Compact Size 12V LiFePO4 Battery Pack  40Ah Lithium Battery In Light Weight

Large Image :  Compact Size 12V LiFePO4 Battery Pack 40Ah Lithium Battery In Light Weight

Product Details:
Place of Origin: China
Brand Name: HECO
Certification: CE,RoHS ,UN38.3, ISO
Model Number: HC-12F40-BM
Payment & Shipping Terms:
Minimum Order Quantity: 10 Packs
Price: Negotiable
Packaging Details: 2 packs/carton, carton size: 570*240*230mm
Delivery Time: Sample: within 15 days;bulk order:25~60 days, based on the order quantity
Payment Terms: T/T (30% advance payment, 70% balance payment to deliver the goods);Western Union, Paypal
Supply Ability: 10000 packs/ month

Compact Size 12V LiFePO4 Battery Pack 40Ah Lithium Battery In Light Weight

Description
Features: Compact Size, Light Weight, Long Cycle Life Nominal Voltage: 12V
Nominal Capacity: 40AH Dimensions: 205*150*88mm
Weight: 4kg Applications: Electric Wheelchair, Solar Energy Storage
High Light:

12v battery pack

,

lifepo4 12v battery pack

Compact Size 12 Volt LFP Battery Pack, 40Ah Lithium Battery In Light Weight



Quick Detail:



1. Soft-pack LiFePO4 cells inside
2. Compact in size and light in weight

3. BMS manages to each cell for high reliability
4. Extra long cycle life - 5 times life of Lead Acid and 2 times of NiMH
5. Extremely safe: No explosion, no fire under collision, over charged or short circuit





Description:





Compact Size 12 Volt LFP Battery Pack, 40Ah Lithium Battery In Light Weight



Compared with the same capacity lead-acid battery, LiFePO4 battery is 1/3 smaller in size, 2/3 lighter in weight, 5 times longer in cycle life, more economic and eco-friendly.

LiFePO4 battery replacing Lead acid battery is an inevitable trend.

Compared with same capacity Li-NixCoyMnz battery, LiFePO4 battery is 2.5 times longer in cycle life, also most the same in weight & size.





Basic knowledge:



Lithium ion battery, classified by the anode material, can be divided into li-MH,Li-Co2, Li-NixCoyMnz, and Li-FePO4, etc.

Classified by the battery shell, can be divided into plastic shell, stell/iron shell and aluminum shell.

All these lithium ion batteries have their own advantages. The technical data of their comparative performances is as follows:



Different Lithium Battery Material Comparision Table
NO. Parameters  Li-Co2 Li-NiCoMn Li-MnO2 LiFePO4
1 Energy density    (g/cm3) 2.8~3.0 2.0~2.3 2.2~2.4 1.0~1.4
2 Specific area         (m2/g) 0.4~0.6 0.2~0.4 0.4~0.8 12~20
3 Capacity density     (Ah/kg) 135~140 155~165 100~115 130~140
4 Voltage 3.7 3.6 3.6 3.2
5 Cycle life >300 >800 >500 >2000
6 Transition metal Poor Poor Rich Very rich
7 Material cost Very high High  Cheap Cheap
8 Environmental performance Contain Co Contain Co & Ni Non-toxic Non-toxic
9 Safety performance Bad Good Better Excellent
10 Application area Small battery Small battery          Small power battery Power battery Power battery Large capacity power supply





Specifications:



Item

Description

Nominal Voltage

12V

Rated Capacity

40Ah

Pack Dimension

205*150*88mm

Internal Impedance

≤100mΩ

Charging Mode

CC/CV

Pack weight

About 4kg

Rated discharging current

5A

Peak discharging current 10A
Rated charging current 8A

Cycle Life

at least 1200 Cycles @ 100%DOD

Charge Temperature

0-60 ℃

Discharge Temperature

-20-60 ℃

The data on the table is only for reference

                Compact Size 12V LiFePO4 Battery Pack  40Ah Lithium Battery In Light Weight 0







Company advantages:



1. Advanced polymer lithium-ion battery technology system ensure the correct technical direction and advanced leading technology
2. Excellent procedure quality tracking control system ensure HECO battery’s excellent performance and good consistency.
3. One-stop lithium battery system solutions. Heco’s research and development team include electronic engineer, mechanical engineer, structure engineer, whom could offer our clients one stop solutions including BMS, charger, battery pack structure, and overall applications.
4. Intimate and in time reacting service system. We always try to offer more than expected, do more than required.



Tag: 12V 40AH LFP battery pack, 12V lithium battery, 40ah lithium batteries
