Product Details:
|
| Features: | Large Capacity, Rack Module Assembly | Battery Chemistry: | LiFePO4 |
|---|---|---|---|
| Battery Volt: | 48V | Battery Capacity: | 1000Ah |
| Dimensions: | 1200*600*1600mm | Weight: | Na |
| Warranty: | 5 Years | Application: | Solar Storage, Home Backup Power Supply |
Overview:
With the emergence of wind & solar power and other new energy sources, the development of intelligent grid technology as well as the large -scale energy storage station is becoming to meet peak power allocation. HECO is developing he environmental-protection lithium-ion energy storage battery with the lightest, fast charge and discharge, cycle life more than than 2,000 times to meet the future demand of energy storage stations and new energy vehicle charging stations. HECO strives to become an advanced enterprise in the energy storage battery industry field.
HECO developped Rack style and Powewall style lithium ion battery bank with excellent safety, high energy density, cell voltage detection, which could be connected with BMS to monitor the matter as well, is most suitable solution for energy storage.
Description:
50KWh Solar Energy Storage Battery , 48V 1000AH Lithium Battery Bank with RS485 Communication Rack Style
Compared with the same capacity lead-acid battery, LiFePO4 battery is 1/3 smaller in size, 2/3 lighter in weight, 5 times longer in cycle life, more economic and eco-friendly.
LiFePO4 battery replacing Lead acid battery is an inevitable trend.
Specifications:
| MODEL# | 48/15K-120/225 | 48/20K-120/225 | ES4820K |
| DATASHEET | |||
| Intergrated PCM/BMS | BMS in, with display panel | ||
| Output Capacity(Wh), D0D=80% | 15K | 20K | 25K |
| Nominal voltage (V) | 48 | 48 | 48 |
| Nominal capacity (Ah) | 300 | 400 | 500 |
| System configuration |
3pcs 48v 100ah module |
4pcs 48V 100AH module |
5pcs 48V 100AH moudle |
| Dimensions (L*W*H in mm) | 600*600*715 | 770*580*1300 | 600*600*1600 |
| Constant charge/ discharge current (A) | 120 | 120 | 300 |
| Maximum charge/ discharge current (A) | 150 (15 seconds) | 225 (3 minutes) | 500 (15s) |
| Standard Charge Voltage (V) | 58.4 | 58.4 | 58.4 |
| Discharge cut-off voltage (V) | 50.4 | 50.4 | 50.4 |
| Approx. Weight (Kg) | 150 | 200 | 250 |
| WORKING CONDITION |
Operating temp. : -20 ~ 60℃ |
||
| ENCLOUSURE | |||
| Common characteristics |
Material : Iron |
||
| Battery connector |
Anen Connector |
||
| STANDARDS | |||
| Safety | EN61000-6-1, EN61000-6-3 | ||
Company advantages:
1. Advanced LiFePO4 lithium battery technology system ensure the correct technical direction and advanced leading technology.
2. Excellent procedure quality tracking control system ensure HECO battery’s excellent performance and good consistency.
3. One-stop lithium battery system solutions. Heco’s research and development team include electronic engineer, mechanical engineer, structure engineer, whom could offer our clients one stop solutions including BMS, charger, battery pack structure, and overall applications.
4. Intimate and in time reacting service system. We always try to offer more than expected and do more than required.
Tag: 50KWh energy storage battery bank, 48V 1000ah lithium battery bank
