3.2V 100Ah Prismatic Aluminium Case LiFePO4 Battery Cell 1C Discharge Rate

Product Details:
Place of Origin: China
Brand Name: HECO
Certification: MSDS, UN38.3, IEC62619, CE, UL,BIS
Model Number: IFP48173125
Payment & Shipping Terms:
Minimum Order Quantity: 100pcs
Price: US$53-US$76
Packaging Details: 4ps/carton
Delivery Time: Sample: within 3 working days, bulk order:10~20 days
Payment Terms: T/T (30% advance payment, 70% balance payment to deliver the goods), , L/C
Supply Ability: 10000 pcs/ day
Contact Now

Detail Information

Voltage: 3.2V Capacity: 100Ah
Dimensions: 48*173*125mm Weight: 2.3kg
Charge Rate: 1C Discharge Rate: 1C
Cycle Life: 3000 Cycles (1C Charge/discharge @25℃)
High Light:

Lithium Ion Battery Cells

,

8Ah Lithium-Ion Battery

Product Description


Features:
1- with original srew holes which is easy for assembly, especially suitable for energy storage
2- low resistance which is 30% higher heat dissipation efficiency compared with peers
3- Extra long cycle life: more than 3000 cycles  under 1C charge/discharge rate @ 25℃

4- full certifications including UN38.3, IEC62619, CB, UL, BIS certificates ensure the cell can enter every market over the world



Parameters:

3.2V 100Ah Prismatic Aluminium Case LiFePO4 Battery Cell 1C Discharge Rate



                      3.2V 100Ah Prismatic Aluminium Case LiFePO4 Battery Cell 1C Discharge Rate



Full Prismatic Cell Models List:

Model Nominal Voltage Nominal Capacity Resistance Coninuous Discharge Current Discharge Cut-off Voltage Charge Current Charge Cut-off Voltage Dimensions (MAX) Approx Weight Cycle Life
  V Ah A V A V mm(T*W*L) kg
IFP27148130-50Ah 3.2 50 ≤2 ≤1C 2.5 ≤1C 3.65 26.7*148.3*129.8 1.05±0.1

≥1500
(0.5C charge /

1C discharge

@ 25℃)

IFP29135185-50Ah 3.2 50 ≤0.7 ≤3C 2.5 ≤1C 3.65 29.3*135.3*185.3 1.395±0.05

≥7000
(0.5C charge /

1C discharge

@ 25℃)

IFP50160118-100Ah 3.2 100 ≤0.5 ≤1C 2.5 ≤1C 3.65 49.9*160*118.5 1.92±0.05

≥2000
(0.5C charge /

1C discharge

@ 25℃)

IFP48173125-100Ah 3.2 100 ≤0.4 ≤1C 2.5 ≤1C 3.65 48*173*125 ≤2.3

≥3000
(1C charge/discharge

@ 25℃)

IFP37130200-105Ah 3.2 105 ≤0.5 ≤3C 2.5 ≤1C 3.65 36.7*130.3*200.5 1.98±0.05

≥3500
(1C charge/discharge

@ 25℃)









Company advantages:
1. Advanced LiFePO4 battery technology system ensure the correct technical direction and advanced leading technology.
2. Excellent procedure quality tracking control system ensure HECO battery’s excellent performance and good consistency.
3. One-stop lithium battery system solutions. Heco’s research and development team include electronic engineer, mechanical engineer, structure engineer, whom could offer our clients one stop solutions including BMS, charger, battery pack structure, and overall applications.
4. Intimate and in time reacting service system. We always try to offer more than expected and do more than required.



Tag: 100ah LiFePO4 battery cell, 100ah LFP cell, 3.2V 100AH LFP cell
