China Electronic Instrument Lithium Batteries manufacturer

Customized 24V LiFePO4 Battery Pack , Rechargeable Li-polymer batteries At 20AH Capacity With High Energy Density

Product Details:
Place of Origin: China
Brand Name: HECO
Certification: CE,RoHS,ISO
Model Number: HC-SL-24F20-A
Payment & Shipping Terms:
Minimum Order Quantity: 50 Packs
Price: Negotiable
Packaging Details: 2 packs/carton, carton size: 570*240*230mm
Delivery Time: Sample: within 15 days;bulk order:25~60 days, based on the order quantity
Payment Terms: T/T (30% advance payment, 70% balance payment to deliver the goods);Western Union, Paypal
Supply Ability: 10000 packs/ month
Contact Now

Detail Information

Nominal Voltage: 24V Nominal Capacity: 20Ah
Weight: Approx 4.2KG Dimensions: 205mm*150mm*88mm Or Customized Design
Application: Solar Energy Storage, Electric Wheelchair, Eletric Scooter

Product Description



Customized 24V LiFePO4 Lithium Battery Pack , 20AH Cpacity With High Energy Density





Quick Detail:



1. Soft-package LiFePO4 cells inside
2. Compact in size and light in weight

3. BMS manages to each cell for high reliability
4. Extra long cycle life - 5 times life of Lead Acid and 2 times of NiMH
5. Extremely safe: No explosion, no fire under collision, over charged or short circuit





Description:



Compared with the same capacity lead-acid battery, LiFePO4 battery is 1/3 smaller in size, 2/3 lighter in weight, 5 times longer in cycle life, more economic and eco-friendly.

LiFePO4 battery replacing Lead acid battery is an inevitable trend.

Compared with same capacity Li-NixCoyMnz battery, LiFePO4 battery is 2.5 times longer in cycle life, also most the same in weight & size.





Basic knowledge:



Lithium ion battery, classified by the anode material, can be divided into li-MH,Li-Co2, Li-NixCoyMnz, and Li-FePO4, etc.

Classified by the battery shell, can be divided into plastic shell, stell/iron shell and aluminum shell.

All these lithium ion batteries have their own advantages. The technical data of their comparative performances is as follows:



Different Lithium Battery Material Comparision Table
NO. Parameters  Li-Co2 Li-NiCoMn Li-MnO2 LiFePO4
1 Energy density    (g/cm3) 2.8~3.0 2.0~2.3 2.2~2.4 1.0~1.4
2 Specific area         (m2/g) 0.4~0.6 0.2~0.4 0.4~0.8 12~20
3 Capacity density     (Ah/kg) 135~140 155~165 100~115 130~140
4 Voltage 3.7 3.6 3.6 3.2
5 Cycle life >300 >800 >500 >2000
6 Transition metal Poor Poor Rich Very rich
7 Material cost Very high High  Cheap Cheap
8 Environmental performance Contain Co Contain Co & Ni Non-toxic Non-toxic
9 Safety performance Bad Good Better Excellent
10 Application area Small battery Small battery          Small power battery Power battery Power battery Large capacity power supply





Specifications:



Item

Description

Nominal Voltage

24V

Rated Capacity

20Ah

Pack Dimension

205mm*150mm*88mm

Internal Impedance

≤100mΩ

Charging Mode

CC/CV

Pack weight

About 4kg

Rated Discharging current 10A
Peak Discharging current 20A
Rated charging current 4A

Over Current Protection

YES

Cycle Life

At least 1200 Cycles @100%DOD

Charge Temperature

0-60 ℃

Discharge Temperature

-20-60 ℃

The data on the table is only for reference

Customized 24V LiFePO4 Battery Pack ,  Rechargeable Li-polymer batteries At 20AH Capacity With High Energy Density



Company advantages:



1. Advanced polymer lithium-ion battery technology system ensure the correct technical direction and advanced leading technology
2. Excellent procedure quality tracking control system ensure HECO battery’s excellent performance and good consistency.
3. One-stop lithium battery system solutions. Heco’s research and development team include electronic engineer, mechanical engineer, structure engineer, whom could offer our clients one stop solutions including BMS, charger, battery pack structure, and overall applications.
4. Intimate and in time reacting service system. We always try to offer more than expected, do more than required.



Tag: 24v 20ah lithium battery, 24v lifepo4 battery pack, 20ah lifepo4 battery pack, 24V rechargeable li-polymer batteries
